GE IC697MDL753 Output Module

GE IC697MDL753 Output Module

Item Number:IC697MDL753
Brand:GE
Price: $300
Lead Time: In stock
Condition: New
Payment: T/T
Shipping Port: Fujian， China
Send Inquiry
Download
Description
Technical Parameters
Product Introduction
IC697MDL753 is a 32-point negative logic discrete output module from the GE Fanuc 90-70 series. With its wide voltage adaptability and strong surge current withstand capability, it is suitable for various industrial load control scenarios. As a negative logic output module, it can be adapted to industrial actuators with specific polarity requirements, while also being compatible with TTL-level operation, allowing for flexible integration into control systems with different signal specifications. The module is equipped with a mechanical key positioning structure, effectively preventing accidental insertion into the slot during installation, ensuring accurate connection between the module and the rack, and safe operation of the equipment.

GE Fanuc IC697MDL753



Technical Specifications



Manufacture

 General Electric(GE)

Model

 IC697MDL753
Part Number IC697MDL753

Description

 5/48 Volt DC 0.5 Amp Negative Logic, 32-Point Output Module

Origin

 USA

Dimension

30*20*5cm

Weight

0.5kg



Product Details

The 5/48 Volt DC 0.5 Amp Negative Logic Output Module IC697MDL753 provides 32 output points in two isolated groups with 16 points in each group.

This is a wide range module in that the rated voltage can be 5 volts DC or 10 to 60 volts DC. It provides a high degree of inrush current at 10 volts to 60 volts, which makes the outputs suitable for a wide range of loads that have such characteristics. It also operates at TTL levels.



The IC697MDL753 module features LED indicators on its top, providing real-time feedback on the operating status of each output point. This allows operators to quickly assess the module's operational status and troubleshoot any issues. It supports MS-DOS configuration software running on Windows systems, enabling customized configuration of module output parameters and fault modes to meet diverse control requirements.



Fusing：

The 5/48 VDC 0.5 Amp Negative Logic Output Module IC697MDL753 has no replaceable fuses. If protection is required, a fuse as specified below may be externally connected to each output point by the user.

 Littlefuse 312.750 (3/4 amp, 250 volt), Fast Acting

 Bussmann AGC-3/4 (3/4 amp, 250 volt), Fast Acting



The module features an isolation voltage of up to 1500VAC, effectively resisting electromagnetic interference in industrial environments and ensuring stable signal transmission. It receives 5VDC power through a rack backplane with a current consumption of only 0.25A, eliminating the need for an external power supply and simplifying wiring. Its switching response is excellent, with both turn-on and turn-off response times ≤1 millisecond, meeting the requirements of high-speed control scenarios.







To avail our best deals for IC697MDL753, contact us and we will get back to you within 24 hours.
