GE FANUC IC300RCS210 CONTROL STATION

The IC300RCS210 is a remote control station module manufactured by GE Fanuc and part of the IC300 OCS series.

IC300RCS210 Features:
Functional Integration: Integrates I/O, controller, and network functionality into a single device.
Network Compatibility: Compatible with CScan and DeviceNet networks.
Mounting Method: Designed for backplane mounting.



IC300RCS210 Technical Specifications
Power Consumption: 150mA at 24VDC, inrush current: 1A for 8ms at 24VDC.
LED Indicators: A Run indicator indicates whether the ladder code is running; an OK indicator indicates whether the module has passed its self-test; a module status indicator monitors RS-232 serial port activity; and a network status indicator monitors CAN port activity.



The IC300RCS210 is similar to the IC300OCS100, IC300OCS200, and IC300OCS250 modules, but the IC300RCS210 lacks the keypad and display. And while the other three modules are designed to be mounted on a panel door, the IC300RCS210 is back panel mounted.



The OCS100 and OCS200 incorporate membrane keypads to allow the operator to enter information into the controller. This same information can be entered via a remote PC using Cscape's Remote Text Term function if the PC is connected to the CsCAN network. The RCS210 does not have a local keypad but still supports Cscape's Remote Text Term function. The faceplate is made of Autotex polyester by Autotype. The material is resistant to most corrosive substances found in industrial environments. The material also holds up well in most industrial conditions. If used outdoors, the material can yellow or crack.
