Product Introduction
Technical Specifications
|
Manufacture |
ABB |
|
Model |
DO820 |
| Part Number | 3BSE008514R1 |
|
Description |
Digital Output Relay 8 ch |
|
Origin |
Sweden |
|
Dimension |
102*119*45mm |
|
Weight |
0.3kg |
Product Details
The DO820 is an 8-channel 230 V a.c./d.c. Relay (NO) output module for the S800 I/O. The maximum output voltage is 250 V a.c./d.c. and the maximum continuous output current is 3 A. All outputs are individually isolated. Each output channel consists of an optical isolation barrier, an output state indication LED, a relay driver, a relay and EMC protection components. The relay supply voltage supervision, derived from the 24 V distributed on the ModuleBus, gives an error signal if the voltage disappears, and the Warning LED turns on. The error signal can be read through the ModuleBus. This supervision can be enabled/disabled with a parameter.
ABB DO820 Digital Output Module | 3BSE008514R1 | 32-Channel Transistor Output | For S800 I/O Systems
Core Product Information
Item Description
Brand ABB
Model 3BSE008514R1
Product Name DO820 Digital Output Module
Type Electronic Module / I/O Module
Output Type Transistor Output (24V DC)
System Compatibility: ABB Freelance Control Systems, ABB AC 800M High-Performance Controllers
Module Type: S800 I/O Series
Features and benefits：
-8 channels for 230 V a.c./d.c. relay Normal Open (NO) outputs
-8 isolated channels
-Output status indicators
-OSP sets outputs to a predetermined state upon error detection
