Item Number:CC-PDOB01 51405043-176
Brand: HONEYWELL
Price: $1400
Lead Time: In stock
Condition: New
Payment: T/T
Shipping Port: Fujian,China
Send Inquiry
Description
Technical Parameters
Product Introduction
Honeywell 51405043-176 CC-PDOB01 is a digital output module that provides digital output functionality for industrial automation systems. It receives digital signals from the control system and drives external devices such as relays and valves to achieve process control.
Off-StateVoltagev 0VDC (max) (3.3VDC (max) indicated under no-load condition)
Off-State Leak Current:5.0 µA (max)
Turn-On/Turn-Off Time:10 ms (max)
Gap (0 current) of Output to Field on Switchover:N one (0ms) (applies to Redundancy only)
Other Features:
High Precision: Each output channel offers high precision, ensuring output signal accuracy.
Fast Response: The module's fast response improves system efficiency and responsiveness.
Easy Integration: Compatible with C300 controllers and other Honeywell control system components, facilitating system integration and maintenance.
Strong Communication Capabilities: Supports Ethernet communication protocols such as Ethernet/IP, EtherCAT, PowerLink, and Profinet, enabling communication with HMIs and management systems for remote monitoring and control.
Function:
The Digital Output bussed 24VDC (DO24V) module provides reliable 24V digital output signals to control other process equipment as well as solenoid valves and interposing relays. The DO24V can support high energy outputs to reduce the number of external components in the output loop.
Bussed 24VDC DO:
The Digital Output Bussed 24VDC has provisions for both internal and external field power excitation. As a bussed output device, all of the outputs share a common return (ground). All outputs get their power from the same source, which can be either the system power supply or an externally connected 24V power supply. When selection is from an external source, outputs can be galvanically isolated from the Series C power system.
Fuse-less Short Circuit Protection
This unique feature allows a short circuit to exist without blowing any fuses. When a particular channel is shorted, internal circuits detect this and remove power to the field connection. The channel remains de-energized until the short circuit is repaired.
FAILOPTThe :
Series C DO module will support the FAILOPT parameter on a per-channel basis. The output can be directed by configuration to either HOLD THE LAST VALUE or SHED to a SAFE VALUE. The safe value can be configured by the user.
