Product Introduction
CC-PAOH01 51405039-175 is a high-performance analog output module from Honeywell's Series C I/O module family. It is primarily used in industrial automation systems to convert digital signals into analog signals to control actuators.
Technical Specifications
|
Manufacture |
HONEYWELL |
|
Model |
CC-PAOH01 |
|
Part Number |
51405039-175 |
|
Description |
Analog Output with HART
|
|
Origin |
USA |
|
Dimension |
20*20*10cm |
|
Weight |
0.65kg |
Product Details
CC-PAOH01 51405039-175 Product Features:
Multi-Channel Output: Supports 16 independent analog output channels for simultaneous control of multiple process variables.
High Accuracy: Provides high-precision analog outputs, capable of delivering reliable 24V DC analog signals, ensuring precise process control.
Communication Protocol Support: Integrated HART (Highway Addressable Remote Transducer) communication protocol enables real-time diagnostics and remote configuration, enhancing maintenance and troubleshooting capabilities.
Self-Diagnostics: Equipped with extensive self-diagnostics, it monitors and reports module health, reducing downtime and maintenance effort.
Redundancy Option: Supports redundant configurations for increased reliability and continuous operation in critical applications.
|
Parameter
|
Specification
|
||
|
Input / Output Model
|
CC-PAOH01 - High-Level Analog Output with HART
|
||
|
IOTA Models
|
CC-TAOX01
|
Non-Redundant
|
6"
|
|
CC-TAOX11
|
Redundant
|
12"
|
|
|
CC-GAOX11
|
Redundant
|
12" | |
|
CC-GAOX21
|
Non-Redundant
|
6" | |
|
Maximum Output Compliant Voltage
(24 V supply = 22 VDC through 28 VDC)
|
16 V
|
||
|
Maximum Open Circuit Voltage
|
22 V
|
||
|
Response Time
(DAC input code to output)
|
settles to within 1% of fthe finalvalue within 80 ms
|
||
|
Gap (0 mA) of Output to Field on Switchover
|
10 ms maximum (applies to Redundancy only)
|
||
