Product Introduction
IC693CPU364 is a single-slot CPU module in the GE Fanuc 90-30 series PLC. Compared with the IC693CPU363 of the same series, it has an internal Ethernet interface, which offers greater communication convenience and is compatible with GE Fanuc's Proficy Machine Edition and other programming software.
Technical Specifications
|
Manufacture |
GE |
|
Model |
IC693CPU364-BD |
| Part Number | IC693CPU364-BD |
|
Description |
Single-slot CPU module |
|
Origin |
USA |
|
Dimension |
30*25*5cm |
|
Weight |
0.55kg |
IC693CPU364-BD Core functional features
Outstanding processing performance
High-speed execution: With an instruction execution speed of 0.2ms/K, it is suitable for complex control tasks with extremely high real-time requirements.
Large-capacity storage: 128K logical memory and 256K data memory, capable of accommodating large-scale control programs and massive process data.
Single-slot design: Saves rack space and provides installation positions for more I/O or special functional modules
Integrated display screen (the core value of the BD suffix)
Local status monitoring: You can directly view it on the front panel of the CPU without connecting programming software or HMI.
CPU operating status (RUN, STOP, FAULT)
System diagnostic information and fault codes
Key process variables (register values that can be displayed through programming definition)
Overview of I/O status
Basic operation functions: Can be performed through the membrane keys at the bottom of the display screen
Run/Stop mode switching
Fault confirmation and reset
View and scroll diagnostic messages
Maintenance convenience: It greatly simplifies on-site debugging, fault detection and daily maintenance work.
Expansion and Compatibility
Compatibility of 90-30 series: Fully compatible with all 90-30 I/O modules, power modules and racks.
System expansion: Supports connection to remote expansion racks through the expansion receiver module.
Network expansion: Distributed control systems can be easily built via Ethernet or Genius bus.
IC693CPU364-BD Product features
Programming and Software
Programming software: Emerson's Proficy Machine Edition - Logic Developer PLC software (or an earlier version of VersaPro) is required.
Function support: Supports programming languages such as ladder diagrams and structured text, and can configure the display content of the screen.
Firmware storage: Programs and firmware are stored in non-volatile memory.
Typical application scenarios
As the main controller of medium to large-scale automation systems.
Applications that require local status monitoring and operation, and reduce reliance on HMI.
A hybrid network environment that integrates Ethernet, serial devices, and Genie's bus is required.
For example: complex production line control, process automation systems, control of large-scale mechanical equipment, etc
The IC693CPU364-BD is a flagship CPU with comprehensive functions and extremely high integration in the 90-30 series. The design of its integrated display screen is distinctive among similar PLCS, providing unparalleled on-site operability of unparalleled for engineers and operation and maintenance personnel. It integrates powerful processing capabilities, rich network communication options and a convenient local diagnostic interface, and is a classic core component for building high-demand automatic control systems.
