Product Introduction
Technical Specifications
|
Manufacture |
General Electric(GE) |
|
Model |
IC690ACC901 |
|
Description |
Miniconverter Kit |
| Compatible PLC series | GE Fanuc 90-30 / 90-70 / 90-20 / 90-Micro PLCs |
| Use the tool software | Logicmaster 90, VersaPro, Proficy Machine Edition |
| Installation method | Directly connect the PC to the PLC for programming or data exchange |
|
Origin |
USA |
|
Dimension |
12*12*3cm |
|
Weight |
0.25kg |
Product Details
IC690ACC901 typically employs industrial-grade molded connectors and reinforced cable protection structures, which are suitable for environments where cables are frequently plugged and unplugged or twisted. It possesses excellent EMI resistance and mechanical fatigue resistance capabilities.
IC690ACC901 Miniconverter Kit
IC690ACC901 usually includes:
A miniature converter module for converting RS-422/RS-485 to RS-232;
A serial extension cable approximately 2 meters (6 feet) long;
A DB9 to DB25 adapter plug
IC690ACC901 can be used in multiple generations of GE series PLC controllers, including but not limited to:
✔ Series 90-30 PLC
✔ Series 90-70 PLC
✔ Series 90-20 PLC
✔ Series 90-Micro PLC, etc.
why choose IC690ACC901 Miniconverter Kit
✅ RS-422/RS-485 ↔ RS-232 signal conversion
Support the conversion of the PLC's serial port (typically GE's SNP or RS-422/485) signal to standard RS-232, making it easier to connect to PCs, laptops, programming devices, or other serial peripheral equipment.
✅ Convenient for on-site debugging and programming of the equipment
Can be used for:
Download / Backup of PLC Program
Online monitoring and debugging
Data collection and fault diagnosis
Communicate with RS-232 peripheral devices such as SCADA, HMI, and printers
Supports Modbus or SNP protocols (depending on the software environment)
This feature makes this Kit highly practical during the on-site debugging, installation, and maintenance stages.
✅ Easy installation, plug-and-play
The product is mainly designed with the "plug-and-play" concept, and does not require complex configuration.
Includes extension cords and adapter plugs, reducing issues related to wire materials and interface compatibility.
Convenient for use and movement in a confined space
✅ Industrial-grade design and compatibility
Wide temperature design suitable for industrial environments
Highly compatible with the GE Fanuc Series 90 PLC system
Often used for upgrading old systems, maintenance,e and long-term operation projects
✅Support and Compatibility Tips
This product is an older communication interface tool in the industrial automation market. Some platforms may have been discontinued, but it is still commonly found in second-hand or inventory channels.
If used in modern PLCs (such as RX3i or PACSystems), it is recommended to confirm the availability of the corresponding serial port interface and the protocol support.
Engineering FAQ
Everything Customers Need to Know
Can it be used over a long distance?
It is recommended to keep the distance within 15 meters. For longer distances, the RS-485 solution needs to be used.
What are the reasons for the unstable communication?
It is mostly caused by poor grounding, interference, or loose serial port cables.
Can it be plugged back in and out online?
Online connection is supported, but frequent hot plugging is not recommended.
How to connect without a serial port?
Use a USB-RS232 converter and install the driver correctly.
