Product Introduction
SCHNEIDER 140DAO84000 is a Discrete Output Module used with the Modicon Quantum PLC system. This module is specifically designed for controlling and switching digital output signals to external devices like actuators, solenoids, relays, and other on/off devices. As part of the Modicon Quantum series, it seamlessly integrates with Schneider Electric's advanced PLC systems, ensuring reliability and precision in industrial automation.
Technical Specifications
|
Brand |
Schneider |
|
Model |
140DAO84000 |
|
Part Number |
140DAO84000 |
|
Description |
Discrete Output Module |
|
Origin |
France |
|
Dimension |
18*13*5cm |
|
Weight |
0.3kg |
Product Details
140DAO84000 Discrete Output Module Detailed Specifications Recap
| Attribute | Specification |
|---|---|
| Output Voltage | 24V DC (nominal) |
| Number of Outputs | 16 outputs |
| Output Current | 0.5A per output |
| Switching Mode | Sinking/Sourcing |
| Output Type | Relay contact output (dry contact) |
| Response Time (ON to OFF) | 10 ms (typical) |
| Response Time (OFF to ON) | 10 ms (typical) |
| Galvanic Isolation | Yes, between the output and logic circuits |
| Temperature Range (Operating) | 0°C to 60°C |
| Temperature Range (Storage) | -25°C to 85°C |
| Humidity Range | 5% to 95% non-condensing |
| Mounting | DIN Rail or Rack Mount |
| Vibration Resistance | Suitable for industrial environments |
| Pollution Degree | 2 (industrial use) |
| Overvoltage Category | III (industrial control systems) |
| Compliance | UL, CE, RoHS Compliant |
| Bus Communication | Modicon Quantum I/O Bus |
| Power Consumption | 2.5W (typical) |
Applications of the 140DAO84000 Discrete Output Module:
Industrial Automation: The module is ideal for controlling various actuators, relays, and solenoids in manufacturing environments, ensuring precise automation and control.
Process Control: In process industries, such as chemical, food and beverage, or pharmaceutical industries, this module can be used for controlling equipment like valves, mixers, or pumps.
Building Management: It is perfect for controlling building systems, including HVAC, lighting, and security systems, allowing remote control from the central PLC.
Robotics: In robotic systems, this module can control digital outputs such as relays that activate motors, sensors, or actuators.
140DAO84000 Discrete Output Module: Performance and Advantages:
Reliability: The 140DAO84000 is built for durability in tough industrial environments, with features like vibration resistance and temperature resilience.
Ease of Integration: Being part of the Modicon Quantum PLC family, this output module can be easily integrated into existing automation systems, ensuring a seamless experience for both operators and maintenance personnel.
Flexibility: With the ability to handle both sinking and sourcing outputs, this module adapts to different wiring needs, making it versatile for a variety of industrial applications.
FAQ
Q: What type of protection does the 140DAO84000 module offer for its outputs?
A: The module includes internal protection through an RC filter, which helps to mitigate noise and voltage fluctuations. Additionally, each output is protected with a 5 A fuse to prevent overcurrent damage.
Q: What is the maximum load current that the 140DAO84000 module can handle?
A: The module can handle a maximum load current of 4 A rms per point for 24 to 115 V applications and 3 A rms for 200 to 230 V applications. The total module capacity is 16 A rms.
Q: What is the response time for the Schneider Electric 140DAO84000 module?
A: The response time for the 140DAO84000 is ≤ 0.5 ms for both transitions from State 0 to State 1 and from State 1 to State 0, ensuring fast and accurate signal processing.
If you have any order needs, please feel free to contact us.
