BENTLY NEVADA 176449-01 3500/40M





176449-01 3500/40M Proximitor Monitor is an important monitoring module in the Bently Nevada 3500 Machinery Protection System for the condition monitoring of rotating machinery. It is mainly responsible for receiving dynamic and static signals from the Bently Nevada eddy current sensors (Proximitor System) and conducting continuous online monitoring of the operating status of key equipment. As a four-channel Proximitor Monitor in the 3500/40M series, this module can be flexibly configured according to the requirements of on-site applications and is widely used in machinery protection (Machinery Protection) and equipment condition monitoring (Vibration Monitoring) systems, providing continuous data acquisition and alarm monitoring functions for critical rotating equipment.

For users who have already deployed the Bently Nevada 3500 series system, this module can be used for both new projects and as an important component for system maintenance, equipment upgrades, and spare parts inventory, helping users maintain the continuous operation and monitoring capabilities of the 3500 Machinery Protection System.

BENTLY NEVADA 176449-01 3500/40M Proximitor Monitor, as a monitoring module in the 3500 mechanical protection system, needs to be combined with the 3500 series chassis, I/O modules, communication modules, and eddy current sensor system to form a complete online monitoring solution. When purchasing spare parts or initiating new projects, confirming the compatibility among all components is helpful in ensuring the smooth progress of system installation, parameter configuration, and subsequent maintenance work.

--3500 Rack

176449-01 is installed in the designated slot at the front of the Bently Nevada 3500 Rack. It enables module power supply, data communication, and system management through the 3500 Rack. The 3500 Rack is designed in a modular manner, allowing for the configuration of power modules, communication modules, monitoring modules, and relay modules according to project requirements, providing a unified platform for supporting the mechanical protection system.
When making the purchase, it is recommended to confirm the slot configuration and system capacity of the 3500 Rack on-site, in order to ensure that the newly added or replaced modules are consistent with the existing system.

--125680-01 Internal Termination I/O Module

125680-01 is the Internal Termination I/O Module specifically designed for the 3500/40M Proximitor Monitor. It is mainly responsible for the connection of on-site sensor signals and the internal terminal connections.
This I/O module is installed at the rear of the 3500 rack and is connected to 176449-01 via the backplane. It is suitable for the centralized wiring method within the control cabinet. For projects with internal wiring design, the Internal Termination structure can reduce the number of external connections, making the internal wiring of the control cabinet more standardized.
During the procurement process, it is necessary to ensure that the Monitor Module and the I/O Module are configured in a corresponding manner to avoid inconsistencies in interface type or wiring method.

--126615-01 External Termination I/O Module

For systems that use on-site terminal block wiring, the External Termination I/O Module can be selected for compatible use.
This type of I/O module supports direct connection of on-site cables to the external terminal block, facilitating on-site installation, maintenance, and line inspection. It is suitable for large-scale installations, long-distance wiring, and industrial applications that require frequent maintenance.
When purchasing, it is necessary to determine whether to use the Internal Termination or External Termination version based on the control cabinet design schematic to ensure that the system configuration is consistent.

--149716-01 TMR I/O Module

In some high-availability mechanical protection systems, the 149716-01 TMR I/O Module can be selected based on the system architecture.
This module is mainly applied to monitoring systems with triple modular redundant (TMR) design requirements, providing higher-level signal input and system fault-tolerance capabilities for critical rotating equipment. Whether to adopt the TMR configuration should be determined based on the on-site system design and project technical specifications.

As the core monitoring module of the 3500 mechanical protection system, the BENTLY NEVADA 176449-01 3500/40M Proximitor Monitor's inspection process typically involves multiple steps such as appearance inspection, hardware status confirmation, channel function verification, sensor signal testing, and system configuration check. Since this module is part of the online mechanical protection system, its performance verification usually requires the combination of the 3500 Rack and the accompanying sensor system, rather than just the individual inspection of the module itself.
