Vibration Monitoring CA202-144-202-000-225 is a CA202 series piezoelectric accelerometer, designed for industrial vibration measurement applications on rotating equipment and high-value mechanical assets. This industrial vibration sensor converts mechanical vibration signals into electrical charge output, providing measurement data for machinery health monitoring systems for turbines, compressors, generators, pumps, and other high-value rotating equipment.
As an original CA202 vibration-monitoring spare part, the CA202-144-202-000-225 features an integrated cable configuration and is commonly used in vibration-monitoring chains that require high-temperature piezoelectric sensing technology. It is suitable for replacement projects, maintenance inventory, and industrial automation system upgrades.
Stock availability, inspection records, technical documents, and RFQ support are available. Contact us for current price, delivery time, and product verification before purchase.
Quick RFQ Information
| Item | Description |
|---|---|
| Model | CA202 |
| Part Number | 144-202-000-225 |
| Product Category | Vibration Monitoring Sensor |
| Sensor Type | Piezoelectric Accelerometer |
| Cable Length | 11 meters |
| Output Type | Charge Output |
| Installation Area | Industrial rotating machinery |
| Availability | Stock inquiry supported |
| Shipping Method | DHL / FedEx / UPS / TNT |
| Warranty | 12 Months |
| Dimension | 17*17*8cm |
| Weight | 0.85kg |
| HS code | 9024900000 |
| Sensor Type | Piezoelectric Accelerometer |
| Sensitivity | 100 pC/g ±5% |
| Frequency Range | 0.5 to 6000 Hz |
| Temperature Range | -55°C to +260°C |
| Output | Charge output |
| Measuring Element | Piezoelectric ceramic sensing element |
| Housing Material | Stainless steel |
| Cable | Integrated low-noise cable |
| Installation | Industrial mechanical mounting |
The CA202 series includes various cable lengths and explosion-proof versions, with different part numbers corresponding to specific installation environment requirements. When purchasing, the exact model must be confirmed based on the site's hazardous area classification, cable length, and system configuration.
What is CA202-144-202-000-225 Used For?
The CA202-144-202-000-225 Piezoelectric Accelerometer is a front-end vibration sensing component used in industrial condition monitoring systems.
Its main functions are:
Detect mechanical vibration generated by rotating equipment
Convert vibration acceleration into electrical charge signals
Send vibration information to a signal conditioner or monitoring system
Support vibration analysis, machinery diagnostics, and preventive maintenance
The sensor itself does not directly provide a standard PLC 4-20mA output. The charge signal normally requires a compatible signal conditioner before connection to monitoring equipment.
Compatible Monitoring Systems
CA202 sensors are commonly integrated into industrial vibration monitoring chains including:
Vibro-Meter / Meggitt Systems
VM600 Machinery Protection System
VM600 CMS Condition Monitoring System
MPC4 Monitoring Card System
IOC4T Input/Output Modules
IPC707 Signal Conditioner
Industrial Automation Platforms
Possible integration applications:
PLC vibration acquisition systems
DCS condition monitoring systems
Turbine protection systems
Compressor monitoring systems
Generator monitoring systems
The following models belong to the same CA202 product family:
| Model | Part Number | Description |
|---|---|---|
| CA202 | 144-202-000-105 | Ex version, 3m cable |
| CA202 | 144-202-000-115 | Ex version, 6m cable |
| CA202 | 144-202-000-225 | 11m cable configuration |
| CA202 | 144-202-000-235 | 20m cable configuration |
| CA202 | 144-202-000-205 | Standard version, 3m cable |
| CA202 | 144-202-000-215 | Standard version, 6m cable |
Product Verification & Inspection Record
To support industrial spare parts procurement, each CA202-144-202-000-225 unit can be supplied with inspection information.
Physical Inspection
Before shipment:
✓ Product appearance inspection
✓ Model label verification
✓ Part number confirmation
✓ Cable and connector inspection
✓ Packaging condition check
Real Product Photos Available
The product page should include:
1. Multi-angle Physical Photos
Recommended images:
Front view of sensor body
Side view showing stainless steel housing
Cable outlet position
Bottom mounting surface
Overall package appearance
2. Nameplate / Label Photos
Show:
Manufacturer label
Model number
Part number
Serial number (if applicable)
3. Packaging Photos
Include:
Anti-static packaging
Shock protection material
Export carton
Shipping label
Installation Notes
CA202 installation requires proper mechanical coupling with the monitored equipment.
Recommended installation procedure:
Clean mounting surface
Ensure flat contact between sensor base and machine surface
Fix sensor using suitable mounting hardware
Route cable away from mechanical interference
Connect sensor output to chargeamplifier/monitoringg module
The installation torque and mounting requirements should follow the applicable CA202 installation documentation.
FAQ
Q: Can CA202 connect directly to PLC?
A: Normally no. PLC systems usually require a signal conditioning module because the CA202 provides charge output rather than standard analog output.
Q: What equipment uses CA202 accelerometers?
A: Typical equipment includes:
Gas turbines
Steam turbines
Compressors
Generators
Large rotating machinery
Q: What is the difference between CA202 standard and Ex versions?
A: The difference mainly relates to certification and installation environment. Ex versions are designed for potentially explosive atmospheres.
Q: Does this sensor replace older Vibro-Meter models?
A: Replacement suitability depends on system design, cable configuration, and monitoring input requirements. Technical confirmation is recommended before substitution.
Q: Is CA202 still available?
A: Availability depends on current stock and supply channels. RFQ confirmation is recommended before purchase.
Q: How can I request a quotation?
A: Send:
Part number
Quantity
Shipping destination
Required delivery date
Our team will confirm price and delivery information.
