TWW103 M1 (VMD-TWW103-M1) Transmitter

The TWW 103 M1 transmitter from Parker Meggitt's vibro-meter® product line is a dedicated onechannel vibration and position measurement transmitter with a 4 to 20 mA current-loop output signal.

A TWW 103 M1 VMD-TWW103-M1 transmitter is used, in combination with a WW 018 proximity sensor, to measure the relative position of a target object without touching the target (that is, the non contact measurement of displacement). Accordingly, such displacement measurement systems consist of a WW 018 proximity sensor and a TWW 103 M1 transmitter, and provide a measurement range (static) of 10 mm.

KEY FEATURES AND BENEFITS:

• From the vibro-meter® product line

• Available in standard versions and Ex versions certified for use in hazardous areas

• One-channel transmitter

• Measurement range: 2 to 12 mm

• Temperature range: 0 to 70°C

• Aluminum housing

• Protection rating: IP66

• Compatible with WW 018 proximity sensor

APPLICATIONS:

• Shaft relative position measurement chains for machinery protection and/or condition monitoring

• General-purpose position monitoring and protection for stand-alone machines in harsh industrial environments and/or hazardous areas
