Description
Technical Parameters
Technical Specifications
|
Manufacture |
GE |
|
Model |
531X305NTBANC |
| Part Number | 531X305NTBANC |
|
Description |
CARD |
|
Origin |
USA |
|
Dimension |
30*10*4cm |
|
Weight |
0.35kg |
MARK*VIE CONTROL
The Mark* VIe control system is a flexible platform used in multiple applications. It features high-speed, networked input/output (I/O) for simplex, dual, and triple redundant systems.Industry-standard Ethernet communications are used for I/O, controllers, and supervisory interface to operator and maintenance stations, as well as third-party systems. The ControlST* software suite, which contains the ToolboxST* toolset, is used with Mark VIe controls and related systems for programming, configuration, trending, and analyzing diagnostics. It provides quality, time-coherent data in the controllers and at the plant level for effectively managing control system equipment. The Mark VIeS Safety control is a stand-alone safety control system for safety-critical applications that conform to IEC®-61508. It also uses the ControlST software suite to simplify maintenance, but retains a unique set of certified hardware and software blocks. The ToolboxST application provides a means to lock or unlock the Mark VIeS for configuration and safety instrumented function (SIF) programming.
A single-board controller is the heart of the system. The controller includes the main processor and redundant Ethernet drivers to communicate with
networked I/O, and additional Ethernet drivers for the control network. Areal-time, multi-tasking operating system is used for the main processor and I/O modules. Control software is provided in a configurable control block language and stored in non-volatile memory. It is similar to IEEE® 854 32-bit floating-point format, and Sequential Function Charts (SFC) are also available for complex sequencing.
