Product Introduction
Emerson PR9268/602-000 is an electrodynamic sensor designed to measure mechanical vibrations. It is suitable for a variety of industrial applications, such as absolute vibration measurement of critical rotating machinery such as steam, gas and water turbines, compressors, pumps and fans.
Technical Specifications
|
Manufacture |
EMERSON |
|
Model |
PR9268/602-000 |
|
PN Number |
PR9268/602-000 |
|
Description |
Electrodynamic Velocity Sensor |
|
Origin |
Germany |
|
Dimension |
35*25*14cm |
|
Weight |
1.2kg |
Product Details
The PR9268/602-000 sensor has high sensitivity and can accurately capture tiny vibration signals and provide precise measurement data.
The wide measurement range can cover various vibration signals from low frequency to high frequency to meet the needs of different industrial applications.
The sensor housing is made of sturdy materials and has waterproof and dustproof properties, which can operate stably and long-term in harsh industrial environments.
The compact design and easy installation can be quickly integrated into the existing monitoring system.
A variety of connection options are provided for compatibility with different monitoring systems.
Self-Powered: The sensor is self-powered.
Operating Temperature Range: -20 to +200°C (-4 to 392°F) for PR9268/60x-000 and PR9268/70x-000 models.
Protection Rating: IP55 for PR9268/20x-x00 and PR9268/30x-x00; IP65 for PR9268/01x-x00, PR9268/60x-000 and PR9268/70x-000.
Relative Humidity: 0 to 100%, non-condensing.
Materials: Al Mg Si Pb F 28 for PR9268/20x-x00 and PR9268/30x-x00; stainless steel for PR9268/01x-x00, PR9268/60x-000 and PR9268/70x-000.
Cable: PTFE, 3x 0.5mm2; armored stainless steel.
Harting plug: die-cast aluminum.
FAQ
Q: About the product status and warranty period
A: Brand new and original with one year warranty.
Q: Delivery time
A: For stock products, we will send goods to you within 2-3 days after receiving the payment.
If we do not have them in stock, usually according to the manufacturer's production cycle
Q: Payment methods
A: 1. We only accpet 100% T/T before shipping;
2. For items with lead time, 30% deposit in advance, 70% balance before shipping;
3. If you have agent in China, please contact us for RMB transfer.
Q: Can you give me a discount?
A: Discount is available, but we have to see the real quantity, we have different price based on different quantity, how much discounts is determined by the quantity, moreover, our price is very competitive in the field.
