Product Introduction
A6740 is a 16-channel output relay card produced by Emerson, designed for the protection system of large rotating machinery. It is used in conjunction with the Emerson AMS 6500 series machinery health monitoring system to achieve remote control and alarm functions of the equipment, ensuring the safe and reliable operation of the equipment. This card is widely used.
Technical Specifications
|
Manufacture |
EMERSON |
|
Model |
A6740 |
|
Part Number |
A6740 |
|
Description |
16-Channel Output Relay Card |
|
MoOrigin |
Germany |
|
Dimension |
24*17*6cm |
|
Weight |
0.43kg |
Product Details
The 16-Channel Output Relay Module is designed for high reliability for the plant's most critical rotating machinery. This 2-slot monitor is used together with the CSI 6500 to build a complete API 670 machinery protection monitor. Applications include steam, gas, compressors and hydro turbo machinery.
Any channel clear, alert or alarm signal can be selected as input to the 16-Channel Output Relay Module. Use Boolean logic, apply time delay, and select an output relay to complete the configuration. Easy-to-use software provides graphical logic displays that guide the user pictorially through configuration.
The CSI 6500 Machinery Health Monitor is an integral part of PlantWeb® and AMS Suite. PlantWeb provides operationsintegrated machinery health combined with the Ovation® and DeltaV™ process control system. AMS Suite provides maintenance personnel advanced predictive and performance diagnostic tools to confidently and accurately determine machine malfunctions early.
| ■ 3U size, 2-slot plu-in module decreases cabinet space requirements in half from traditional 6U size cards |
| ■ API 670 compliant, hot swappable module |
| ■ 60 inputs, 30 logical expressions, 16 relay outputs |
| ■ 6740 is a 12TE wide module for IMR6000 series rack |
| ■ 6740-10 is the 10TE wide module for the IMR6500 series rack |
