Schneider 140ACI03000 Analog Input Module

Schneider 140ACI03000 is a Modicon Quantum series analog input module. The module features 8 differential input channels and is compatible with various types of industrial standard signals, such as voltage and current. Its compact design saves space in the control cabinet and is fixed by an installation plate. It supports rack-mounted integration.





Brand	Schneider
Model	140ACI03000
Part Number	140ACI03000
Description	Analog Input Module
Origin	France
Dimension	18*13*5cm
Weight	0.3kg



The Quantum 140AC103000 Analog Input Module provides(8differential analog input channels. Each channel is individually configurable for a 1 ... 5 VDC or 4 ... 20 mA signal.
This module has broken wire detection in current mode and undervoltage in voltage mode.

A Quantum removable terminal strip allows for easy maintenance.
Quantum backplanes (ordered separately) come in 2,3,4,6,10, and 16-slot versions. Any Quantum module can be used in any slot. A  quantum power supply is required in each rack. The power supply provides logic power to all modules on the bus.

All Quantum l/O modules are optically isolated from the bus, ensuring safe and trouble-free operation. This isolation also allows modules to be hot-swapped.
Optionally, you can insert mechanical keys between the l/O module and the terminal strip to ensure that the field wiring and the module type are properly matched. Key codes are unique for each module type. Keykits are shipped with each l/O module.

As an option, modules can be ordered with a conformal coating applied to protect the internal circuitry from corrosive gases such as Chlorine. Nitric Oxide, Hydrogen Sulfide, and Sulfur Dioxide.





140AC103000 Main features

1 . Input signal type

Multiple input support: 140ACI03000 supports multiple analog signal inputs, including voltage (0-10V), current (4-20mA), etc. This enables it to adapt to different types of sensors and field devices, and is widely used in industrial automation control systems to meet various measurement requirements.

Signal accuracy: The module offers high signal accuracy, which helps ensure the accuracy of input datareducesce err, or enhances the control accuracy of the system.



2.Number of channels

16-channel input: 140ACI03000 offers up to 16 analog input channels, allowing users to flexibly configure and expand according to system requirements. These channels can be independently configured for different signal types to meet various on-site measurement requirements.

Channel isolation: Each channel of the module has a certain degree of electrical isolation to ensure that no interference occurs when multiple signal inputs are running simultaneously in the system



3.High-speed sampling and conversion

Fast data acquisition: The 140ACI03000 module adopts high-speed sampling and data conversion technology, capable of real-time acquisition and processing of analog signals. It is suitable for applications with high requirements for response time. For instance, in process control or safety monitoring systems that require high-frequency monitoring, this module can provide timely feedback.

High resolution: This module features a resolution of 12 bits or higher, ensuring the acquisition of minute signal variations, enhancing data accuracy and system responsiveness.



4.Compatibility and easy integration

Modicon M340 series compatibility: As a product of Schneider Electric, the 140ACI03000 module is compatible with the Modicon M340 series PLC and its expansion modules, and is suitable for modern automatic control systems.

Standard communication protocol: Supports Modbus protocol (RTU/TCP), enabling seamless connection with multiple controllers and remote devices to ensure reliable data transmission.

Compatibility with other PLC systems: In addition to the Modicon M340 series, this module is also compatible with other PLC systems that comply with the Modbus protocol, ensuring wide application in various automation systems.Modular design and installation

DIN rail mounting: The 140ACI03000 module adopts the DIN rail mounting method, which is convenient for quick installation and disassembly. The module is of moderate size, making it easy to install in a limited space.

Modular system: Through modular design, users can flexibly expand the system according to their needs, easily add more input modules, and adapt to larger-scale automation systems



7.Diagnostic function and status monitoring

Real-time status monitoring: This module is equipped with an in-built status monitoring function, which can provide real-time feedback on the working status of the module and help users promptly identify potential issues.

Fault Detection and Diagnosis: It provides basic fault diagnosis functions. When a module malfunctions, the system can promptly notify users to carry out maintenance through alarms, fault codes, or other means, avoiding prolonged system d owdowntimeironmental adaptability

Wide operating temperature range: The operating temperature range of the module is from -25°C to +70°C, making it suitable for a variety of complex industrial environments. Whether in high-temperature or cold environments, the module can maintain excellent working performance.

Anti-interference capability: The module has a certain ability to resist electromagnetic interference and electrical noise, ensuring stable operation in an environment with high electromagnetic interference.
