Product Introduction
An FBM216 pair provides up to eight redundant HART® input channels. In a repair situation, when a single module is replaced the inputs are maintained by the redundant module. HART inputs are electrically compatible with 4-20 mA signals, permitting the plant to upgrade field devices without the need to change the control system.
Technical Specifications
|
Brand |
FOXBORO |
|
Model |
FBM216b P0927AJ |
|
Part Number |
FBM216b P0927AJ |
|
Description |
I/A Series Communication Input Module |
|
Origin |
USA |
|
Dimension |
15*15*6cm |
|
Weight |
0.34kg |
Product Details
FOXBORO FBM216b P0927AJ Communication Input Module：
| Mounting |
|
MODULE FBM216b mounts on a modular baseplate. The baseplate can be mounted on a DIN rail (horizontally or vertically), or horizontally on a 19-inch rack using a mounting kit. Refer to Standard 200 Series Baseplates (PSS 31H-2SBASEPLT) for details. TERMINATION ASSEMBLY The TA mounts on a DIN rail and accommodates multiple DIN rail styles including 32 mm (1.26 in) and 35 mm 1.38 in). |
| Weight |
|
MODULE 284 g (10 oz) approximate TERMINATION ASSEMBLY Compression 181 g (0.40 lb) approximate |
| Dimensions – Module |
|
HEIGHT 102 mm (4 in) 114 mm (4.5 in) including mounting lugs WIDTH 45 mm (1.75 in) DEPTH 104 mm (4.11 in) |
| Part Numbers |
|
FBM216b P0927AJ REDUNDANT ADAPTER P0924DT |
| Termination Cables |
|
CABLE LENGTHS Up to 30 m (98 ft) CABLE MATERIALS Polyurethane or Low Smoke Zero Halogen (LSZH) CABLE CONNECTION – TA FBM Baseplate End 37-pin D-subminiature Termination Assembly End 25-pin D-subminiature |
| Field Termination Connections |
|
COMPRESSION-TYPE ACCEPTED WIRING SIZES Solid/Stranded/AWG 0.2 to 4 mm2/0.2 to 2.5 mm2/24 to 12 AWG Stranded with Ferrules 0.2 to 2.5 mm2 with or without plastic collar |
Cables Types and Part Numbers
|
Cable Length m (ft) |
Type 1 P/PVC(a) |
Type 1 LSZH (b) |
Type 1 H/XLPE(c) |
| 0.5 (1.6) | P0916DA | P0928AA | P0916VA |
| 1.0 (3.2) | P0916DB | P0928AB | P0916VB |
| 2.0 (6.6) | P0931RM | P0928AC | P0931RR |
| 3.0 (9.8) | P0916DC | P0928AD | P0916VC |
| 5.0 (16.4) | P0916DD | P0928AE | P0916VD |
| 10.0 (32.8) | P0916DE | P0928AF | P0916VE |
| 15.0 (49.2) | P0916DF | P0928AG | P0916VF |
| 20.0 (65.6) | P0916DG | P0928AH | P0916VG |
| 25.0 (82.0) | P0916DH | P0928AJ | P0916VH |
| 30.0 (98.4) | P0916DJ | P0928AK | P0916VJ |
(a) P/PVC is polyurethane outer jacket and semi-rigid PVC primary conductor insulation. Temperature range; - 20 to +80°C (-4 to +176°F).
(b) Low smoke zero halogen or low smoke free of halogen (LSZH) is a material classification used for cable jacketing. LSZH is composed of thermoplastic or thermoset compounds that emit limited smoke and no halogen when exposed to high sources of heat. Temperature range: -40 to +105°C (-40 to +221°F)
(c) H/XLPE is Hypalon outer jacket and XLPE (cross-linked polyethylene) primary conductor insulation. Temperature range: -40 to +90°C (-40 to +194°F). Hypalon cables are no longer available for purchase.
