Product Introduction
The relay unit (89AR30 GKWN000326R0100) is primarily designed to activate the triggeringcontrol elements of protection systems. It is mounted in a standard with drawable compartment acc. to DlN, using 3 units and including a female connector.
Technical Specifications
|
Manufacture |
ABB |
|
Model |
89AR30 |
|
Part Number |
GKWN000326R0100 |
|
Description |
Relay Unit |
|
Origin |
Germany/ Switzerland |
|
Dimension |
25*15*5cm |
|
Weight |
0.415kg |
Product Details
89AR30 GKWN000326R0100 contains prototype-tested relays with posi-tively driven contacts. The contacts of relays K1, K2, k3 aregrouped in two circuits and are wired in 2-out-of-3 order according to the open-circuit principle (external jumpers B18- B20).
Auxiliary contacts can be used to interrogate the individualrelay positions. Relays K4, k5, and K6 are freely available. k4 may be used forinstance for the emergency trip pushbutton of a certain protec. tion circuit either based on the closed-circuit or the open. circuit principle. In that case, the required jumpers need to be positioned on the edge connector.
