Product Introduction
KC3020X1-BA2(13P0050X012) is a DO (Digital Output) 32-Ch (Channels) 24VDC High-Side Plus Card for DeltaV distributed control systems.
Technical Specifications
|
Manufacture |
EMERSON |
|
Model |
KC3020X1-BA2 |
|
Part Number |
13P0050X012 |
|
Description |
DO 32-Ch 24VDC High-Side Plus Card |
|
Origin |
USA |
|
Dimension |
26*26*5cm |
|
Weight |
0.43kg |
Product Details
- Flexible and Modular Design The Traditional I/O subsystem is designed for flexibility and modularity, simplifying the installation process. It is ideally suited for on-site device proximity installations.
- Built-In Protection for Reliable Connections Featuring function and field wiring protection keys, this I/O model guarantees that the correct I/O card is always plugged into the designated terminal block.
- Smart Choice for Process Control Thanks to its modular design, protective keys, and plug-and-play capabilities, DeltaV™ Traditional I/O stands out as a smart choice for meeting the demands of your process control system.
|
Common Environmental Specifications for all I/O Interfaces
|
| KC3020X1-BA2 13P0050X012 |
|
Category
|
Specifications
|
|
Operating temperature
|
0 to 60 °C (32 to 140 °F)
|
|
Operating temperature
|
-40 to 70 °C (-40 to 158 °F)
|
|
Storage temperature
|
-40 to 85 °C (-40 to 185 °F)
|
|
Relative humidity
|
5 to 95% , non-condensing
|
|
Airborne contaminants
|
ISA-S71.04-1985 Airborne Contaminants Class G3
Conformal coating
|
|
Protection rating
|
IP 20, NEMA 12
|
|
Hazardous area/location
|
ATEX 3 G IIC T4
Class 1, Div 2, Groups A, B, C, D, T4
|
|
Shock
|
10 g ½-sine wave for 11 ms
|
|
Vibration
|
1 mm peak-to-peak from 2 to 13.2 Hz;
0.7 g from 13.2 to 150 Hz
|
|
Dimensions
|
H 10.7 cm (4.2 in.)
W 4.1 cm (1.6 in.)
Depth 10.5 cm (4.1 in.)
|
