Product Introduction
Technical Specifications
|
Manufacture |
ABB |
|
Model |
SC520 |
| Part Number | 3BSE003816R1 |
|
Description |
Submodule Carrier incl. local CPU |
|
Origin |
Sweden |
|
Dimension |
48*28*3cm |
|
Weight |
0.742 kg |
Product Details
Three variants of submodule carriers are available to fit into the RF533 Series controller subrack.
A submodule carrier has no complete function but two slots for submodules of different kinds to define the desired function.
Communication interfaces are the most common category of submodules.
The actual application determines which submodule carrier to use.
Design considerations are given in the controller documentation.
Permit flexible functional dispositio.n
Variants without CPU resources.
The significant differences between available variants are：
SC510 General submodule carrier without slave processor.
SC520 Includes slave processor and protocol turn MasterBus 300 or MasterBus 300E(Submodule CS513 needed).
Indicators：
LED RUN (green) on module front. Indicates module running normally
LED F, Fault (red) on module front.
